Yamaha UR22C Audio Interface - Black
SKU code: VHX7540
Despite its minimalist footprint, the URX22C packs serious creative power. With professional-grade sound, flexible DSP processing, and a full suite of Steinberg production tools, it gives you everything you need to record, produce, or stream from virtually anywhere - with impressive quality and ease.
Specifications
Dimensions
H: 159 mm (6.3")
D: 47 mm (1.9")
W: 159 mm (6.3")
Weight: 1.0 kg (2.0 lb)
Features
- USB Type-C Audio/MIDI Interface with 32-bit integer / 192 kHz support
- MIDI input and output
- 2 D-PRE mic preamps with +48 V phantom power and Mono switch
- 2 Mic/Line Combo inputs: XLR / 6.3 mm jack - Hi-Z switch on input 2 for electric guitar
- 2 TRS line outputs, 1 Headphones output
- Input mixing channels: 2 mono + 3 stereo loopback + 1 FX
- Busses: 1 MIX (Stereo) + 1 FX + 1 STEREO
- Three-channel loopback enables flexible streaming and communication setups.
- Effects powered by the internal DSP and Basic FX Suite give your sound a professional finish.
- Latency-free DSP monitoring with FX for enhanced performance
- Sturdy metal housing
- Includes Cubase AI for PC, Cubasis LE DAW app for iPhone/iPad, Steinberg Plus and USB cable
- USB 3.0 power supply (optional power supply for USB 2.0 required)
- Dimensions (W x H x D): 159 x 47 x 159 mm (6.3" x 1.9” x 6.3”)
- Net weight: 1.0 kg (2.0 lb)
- USB Type-C Audio/MIDI Interface with 32-bit integer / 192 kHz support
- MIDI input and output
- 2 D-PRE mic preamps with +48 V phantom power and Mono switch
- 2 Mic/Line Combo inputs: XLR / 6.3 mm jack - Hi-Z switch on input 2 for electric guitar
- 2 TRS line outputs, 1 Headphones output
- Input mixing channels: 2 mono + 3 stereo loopback + 1 FX
- Busses: 1 MIX (Stereo) + 1 FX + 1 STEREO
- Three-channel loopback enables flexible streaming and communication setups.
- Effects powered by the internal DSP and Basic FX Suite give your sound a professional finish.
- Latency-free DSP monitoring with FX for enhanced performance
- Sturdy metal housing
- Includes Cubase AI for PC, Cubasis LE DAW app for iPhone/iPad, Steinberg Plus and USB cable
- USB 3.0 power supply (optional power supply for USB 2.0 required)
- Dimensions (W x H x D): 159 x 47 x 159 mm (6.3" x 1.9” x 6.3”)
- Net weight: 1.0 kg (2.0 lb)
| SKU | VHX7540 |
| Brand | Yamaha |
| Shipping Weight | 1.0000kg |
| Shipping Width | 0.160m |
| Shipping Height | 0.050m |
| Shipping Length | 0.160m |
| Shipping Cubic | 0.001280000m3 |
| Unit Of Measure | ea |
