Standard Features

• Gig-ready keyboard with pro sounds, an intuitive workflow, enhanced performance features, and support for USB-C mobile battery power
• Instant access to essential sounds for live band performances, including acoustic and electric pianos, organs, synths, and other stage favorites
• Flagship-class ZEN-Core engine with over 3800 ready-to-play sounds
• Expand your creative possibilities with Sound Packs and Wave Expansions on Roland Cloud
• Sample import function for playing and editing user WAV files
• Easy sound manipulation with hands-on knobs and sliders and the classic Roland pitch bend/mod lever
• Eight phrase pads for playing drum sounds and samples, triggering rhythm patterns and audio files, and muting tracks
• Large color display for access to creative modes, sound selection, and sequencer control
• Mic input with dedicated noise suppressor, EQ, reverb, and compressor, plus vocoder and auto-pitch effects for impressive vocal performances
• Intuitive eight-track pattern sequencer for quickly developing song ideas and creating on-the-fly backing tracks
• Class-compliant USB-C audio/MIDI interface with a plug-and-play connection to mobile devices and computers, great for livestreaming and audio content creation
• Acclaimed PHA-4 keyboard with 88 keys and weighted hammer action
• Portable design (32 lb./14.5 kg) for easy travel and effortless setup

Keyboard

Keyboard

88 Keys (PHA-4 Standard Keyboard: with Escapement and Ivory Feel)

Sound Generator

Parts

8

TONE

ZEN-Core

* ZEN-Core Tones can be imported and exported.

Tones

3,800 tones or greater
95 Drum kits or greater

Expansion

EXZ Series

* The expansion are rewritable internal sound generator memory.
You can download data from the Roland Cloud and write it via a USB flash drive into the internal memory.

Preset Scene

128 scenes x 2 bank

User Scene

128

Scene Remain

Yes

Favorite

128

Effects

Multi-Effects: 8 systems, 93 types
Part EQ: 8 systems
Drum Part COMP: 6 systems
Insertion Effect: 1 system, 93 types
Chorus: 10 types
Reverb: 8 types
System EQ: 1 system
Mic Reverb: 8 types
Mic NS/Comp

Vocoder

Band: 13
Type: Mono

Step Sequencer

8 Tracks (per secne)
Maximum 64 steps
Recording Method: Realtime recording, Step recording, TR-REC
Editing Method: Step edit

Audio File Player Section

Audio file: WAV, AIFF
File format: 44.1/48 kHz, 8/16/24 bits

Other

Rhythm Pattern

Yes

Arpeggio

Yes

Chord Memory

Yes

Controllers

Pitch Bend/Modulation lever
Sound Modified knob x 4
Slider x 4
2 x 4 Pads

Display

Graphic color LCD (480 x 272 dots with backlight)

Connectors

Headphones jack: Stereo 1/4-inch phone type
MAIN OUT jacks (L/MONO, R): 1/4-inch TRS type
Mic Input jack: 1/4 inch phone type/XLR type
External Input jack: Stereo miniature phone type
FOOT PEDAL jacks(HOLD, CONTROL)
MIDI connectors (IN, OUT)
USB MEMORY port: Type-A (Storage)
USB COMPUTER port: USB Type-C(R) (Class Compliant for Audio and MIDI/ Roland driver for Audio and MIDI)

External Memory

USB Flash drive (sold separately)

Power Supply

AC Adaptor
USB bus power supply (USB Type-C(R) port)

* External power supply from a USB Type-A port isn't available.

Current Draw

700 mA (AC adaptor)
2,000 mA (USB bus power supply)

Power consumption when in OFF mode (when the power automatically turns off)

0.2 W

Accessories

Startup Guide
Leaflet “USING THE UNIT SAFELY”
AC adaptor (PSB-5U)
Power cord

Options (sold separately)

Keyboard Stand: KS-G8B, KS-11Z, KS-13, KS-20X
Pedal Switch: DP series
Expression Pedal: EV-5

Size and Weight

Width

1,393 mm
54-7/8 inches

Depth

355 mm
14 inches

Height

138 mm
5-7/16 inches

Weight

14.5 kg
32 lbs
